tedee Relay Module

Discover the complete freedom of keyless life

The relay module is an electronic controller for locking devices. It unlocks a mechanism with an electric signal instead of a key. It is a popular tool with multiple applications that is used daily with your intercom, garage door, or office entrance. Any relay-controlled equipment requires a power source and an ‘unlock’ button, remote, PIN pad, or fob reader. These devices’ confirm’ the users accessing the device and then permit them to unlock their hardware. But what if you could unlock all of your devices using your smartphone? That's exactly what the smart relay module in combination with the tedee app offers you!

How does it work?

The tedee smart relay module is an optional accessory for your existing relay controller. Wire it into the assembly and connect the controller to the internet using your local Wi-Fi network or mobile data router. This will ensure that you create a universal wireless connection between the relay device and your smartphone. The module can be accessed via your local WiFi network and the internet and integrated with an online cloud platform. The installation process for the Tedee smart relay module involves an electronic connection, connection to the online cloud service, and subsequent systems integration with the Tedee app. The Tedee smart relay module should only be installed by qualified installers or electricians.

Keep in mind that the smart relay module can only work when your smartphone is connected to the internet. Please note that there is no short-range Bluetooth or direct Wi-Fi connection for local control of the device. If you're installing a relay controller for a device in places without an internet connection, such as underground garages or enclosed hallways, you'll need to find an internet connection to unlock it.

Tedee relay module at your home

Never look for keys, remotes, or parking cards again. Make your returns home an easier and hassle-free experience. There’s no need to manually unlock fence gates and garage doors. You can now relax and unlock all of them in the Tedee app. The smart relay module works in private homes and shared properties such as residential buildings, condominiums, or townhouses. It is connected inside the relay controller. Its installation is a minor and reversible addition to your building's hardware, however, in the case of shared properties, it is advisable to contact the property management first to confirm the location of the controller and permission for installation in advance. Installation of the relay module involves hardware modification of the lock relay control unit and connection of multiple wires. We therefore recommend that you delegate its installation to professionals.

How can the tedee relay module help you?

Security of the street entrance

Management and access control of the fence gate

Smart garage door control

Tedee relay module at your business

Would you like to keep your company’s access management in one place – even in multiple locations, using various types of equipment, and with unlimited employees? Integrating your lock relays with the Tedee desktop portal makes the administration of all access points easy, affordable, and wireless for your business. Create accounts for individual employees, set permissions for their access to restricted areas, or restrict access for a limited time. All of these permissions can be easily modified or revoked whenever personnel changes occur. In addition, the portal, like the app, allows you to view detailed activity logs for your tedee devices. A complete event history is available, allowing you to remotely check if your employees are present or if they arrived at work on time. Forget about changing keys, PIN codes, or the hassle of losing access cards – you won't need them anymore!

How can the tedee relay module help you?

Office door security

Smart parking barrier control

Fence gate management and access control

Tedee relay module at your rental

Relax as a host while offering your guests the much-requested freedom and flexibility to enter and leave your rental property. Access will be on your terms and under your control at all times. As the owner of a tedee smart relay module, you will be able to share virtual keys to the module to enable door unlocking via the tedee app. Your guests will receive an email and after logging into the app, they will unlock the door with a single click on their smartphone. The latest feature introduced by tedee smart devices is access link sharing. This allows your visitor to control all devices at your rental – whether it's an individual apartment's smart lock or a common entrance relay – without having to install the app. Once they receive the link, they simply click on it and unlock the door by swiping the slider.

How can the tedee relay module help you?

Security of the street entrance

Managing access to the community area

Manage and control access to the fence gate/parking gate

Tedee portal and its tools for hosts

You can manage your guests' access not only in the mobile app but also in the tedee portal in the web browser. As with all tedee devices for access control, you can set the dates and times when visitors to your rental can use the virtual keys. For example, their app would only unlock the door during the booked stay, becoming inactive before the hour of arrival and automatically expiring after the hour of departure. You can also generate the aforementioned access link in the portal, configure it with the same detailed settings, and then share this link in your preferred way: via email or messaging app. You will especially appreciate the clear desktop view if you manage multiple rental properties.

The management of access on a desktop computer can be used by anyone, even ordinary users for private purposes. In order to control your smart locks on the web portal, you need to pair them with a Tedee bridge connected to the internet and have an account created in the mobile app. The web portal can be found at the address portal.tedee.com. Here you can also try the demo version, just use the login credentials below. To help you navigate the tedee portal, you can also watch this this video tutorial.

Login: demo.tedee@gmail.com

Password: DemoTedee1!

Features summary

Smart relay module

Providing access to selected areas without keys, PIN codes, and access cards

Unlocking via app

Manage and share access, individual settings

Monitoring of relay module activity

Requires internet connection

Control via app or tedee portal

Note: Although the relay module comes with a manual, we recommend that you contact professionals to install it

Technical specifications

Power supply voltage: 12-24V AC/DC

Power consumption: less than 1W

Number of outputs:1

Max. voltage: 6A 24V AC 6A 24V DC

Type of inputs: 3

Inputs: logic, COM closed

Input Voltage: 12 - 24V AC/DC

Galvanic isolation: yes, optical

Input polarization: automatically detected

Housing: made of halogen-free polyurethane composition, self-extinguishing for thermal class B (130 C)

Degree of protection: IP20

Mounting: flush mounting in the receiver housing

Transmission: bidirectional, encrypted

Transmission frequency: 2.4 GHz

Communication standard: WiFi, WiFi compatible

Wi-Fi connection via standard router

Control output type: NC/NO relay

Maximum power: 144VA @ 24V AC 144W @ 24V DC

Dimensions: 39 x 39 x 22 mm

Documentation

tedee relay module – manual ENG

tedee relay module – FAQ
